No.12-hex bolt ISO4014 half Thread A193 B8, B8M, B8T, B8C SS fastener

Em bi piranî ASTM A193 Gr re peyda dikin. B8, B8M, B8T, B8C Hex Bolt, Bolt Stud, Allen Bolt, û ASTM A194 Gr. 8, 8M, 8T, 8C hebên hexek giran

Berhemên me bi berfirehî di endazyariya neft û gazê, endezyariya petro-kîmyewî de, qereqola hêzê, endezyariya deryayî, endazyariya navokî, makîneyên giran, asîman hwd.

Berçavkirin	Sinif	Mal	Mezinahiya Nomînal Range (nav.)	Taybetmendiyên Mekanîzmayî
				Hêza Yekta, min, 0.2 % berevajî, ksi	Tensile Qawet, min, ksi	Ongarezekirin di 4 D, min%	Kêmkirinî of Area, min%	Zehf, max
ASTM A193 Grade B8	Pola 1 Class 1A	AISI 304	Hemû diameter	30	75	30	50	223HB an 96HRB^C
ASTM A193 Grade B8M		AISI 316
ASTM A193 Grade B8T		AISI 321
ASTM A193 Grade B8	Pola 2	AISI 304 Strain Hardened	3/4 û bin	100	125	12	35	321HB an 35HRC
			3/4 ber 1 incl	80	115	15
			1 ta 1-1 / 4 incl	65	105	20
			1-1 / 4 ber 1-1 / 2 incl	50	100	28	45
ASTM A193 Grade B8M			3/4 û bin	95	110	15
			3/4 ber 1 incl	80	100	20
			1 ta 1-1 / 4 incl	65	95	25
			1-1 / 4 ber 1-1 / 2 incl	50	90	30
ASTM A193 Grade B8T		AISI 321 Strain Hardened	3/4 û bin	100	125	12	35
			3/4 ber 1 incl	80	115	15
			1 ta 1-1 / 4 incl	65	105	20
			1-1 / 4 ber 1-1 / 2 incl	50	100	28	45
ASTM A193 Grade B8M	Class 2B	AISI 316 Strain Hardened	2 û bin	75	95	25	40
			2 ji 2-1 / 2 incl	65	90	30
			2-1 / 2 ber 3 incl	55	80
	Class 2C		2 û bin	65	85		60
			Zêdetirî 2	60

Berçavkirin	Mal	Sinif	Mezinahiya Nomînal (In.)	Stressiya Load Proof (ksi)	Hardness Rockwell		Type Nut
					Min	Max
ASTM A194 Grade 8	AISI 304	Pola 1	Hemû diameter	80	B60	C32	Xwarzê hebekek giran Hezek heb qulikê Xwarzê heb
ASTM A194 Grade 8M	AISI 316	Pola 1 Pola 2		110
ASTM A194 Grade 8T	AISI 321			110

Agahdariya Bilez

Cihê Origin: Jiangsu, Chinaîn (Mainland)
Navê Brand: QFC, HPF
Hejmara Modelê: 1/2 "-4"
Standard: ANSI
ASTM A193: Boltên stud yên B8, B8M, B8T, B8C
ASTM A194: 8, 8M, 8T, nivînên 8C
